Removal Procedure

  1. Remove the front door trim panel. Refer to Trim Panel Replacement - Side Front Door .
  2. Remove the front door water deflector. Refer to Water Deflector Replacement - Front Door .
  3. Remove the front door conduit. Refer to Rubber Conduit Replacement - Front Door .
  4. Remove the front door window belt inner sealing strip. Refer to Sealing Strip Replacement - Front Door Window Belt Inner .
  5. Remove the front door window weatherstrip. Refer to Weatherstrip Replacement - Front Door Window .
    Fig 1: Removing Front Door Window Weatherstrip
    G01814042Courtesy of GENERAL MOTORS CORP.
  6. Remove the front door window. Refer to Window Replacement - Front Door .
  7. Remove the outside rearview mirror. Refer to Mirror Replacement - Power (With Turn Signal Indicator)  or Mirror Replacement - Power (Without Turn Signal Indicator) .
  8. Remove the front door module. Refer to Door Module Replacement - Front .
  9. Remove the front door outside handle. Refer to Door Handle Replacement - Front Outside .
  10. Remove the front door lock. Refer to Lock Replacement - Front Door .
  11. Remove the front door window belt outer sealing strip. Refer to Sealing Strip Replacement - Front Door Window Belt Outer .
  12. Remove the front door window run channel. Refer to Window Run Channel Replacement - Front Door .
  13. Remove the front door molding. Refer to MOLDING REPLACEMENT - DOOR BODY SIDE .
  14. Remove the front door hinges. Refer to Hinge Replacement - Front Door .
  15. With an assistant, remove the front door from the body.
