Removal Procedure

  1. Raise the vehicle.
  2. Support the vehicle with suitable safety stands.
  3. Remove the nut (2) retaining the jounce bumper (1) to the lower control arm.
  4. Remove the jounce bumper (1) from the vehicle.
    Fig 1: Removing Nut & Jounce Bumper
    G01688172Courtesy of GENERAL MOTORS CORP.
