Removal Procedure

  1. Remove the rear door trim panel.
    CAUTION: When working with any type of glass or sheet metal with exposed or rough edges, wear approved safety glasses and gloves in order to reduce the chance of personal injury.
  2. Remove the screws (1) that retain the latch to the door.
  3. Remove the screws that retain the hinge (3) to the door.
  4. Remove the window assembly from the vehicle.
Fig 1: Removing Screws Retaining Latch & Hinge To Door
G01736790Courtesy of GENERAL MOTORS CORP.
