Installation Procedure

  1. Install the power window switch (10) to the escutcheon.
  2. Push the power window switch (10) in order to engage the locking tabs.
  3. Install the escutcheon and the power window switch (10) to the front door trim plate (1).
  4. Push the escutcheon and the power window switch in order to engage the retaining clip.
  5. Install the electrical connector (3) to the power window switch.
  6. Install the front door trim plate (1). Refer to Door Trim Plate Replacement (Manual Windows)  or Door Trim Plate Replacement (Power Windows)  or Door Trim Plate Replacement (Side/Rear Door)  .
Fig 1: Installing Power Window Switch
G01736949Courtesy of GENERAL MOTORS CORP.
