Installation Procedure

WARNING: This page is about a different car, the 2002 Oldsmobile Intrigue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Position the antenna cable to the vehicle.
    NOTE: Refer to FASTENER NOTICE
  2. Install the antenna cable bracket screw.

    Tighten

    Tighten the antenna cable bracket screw to 2 N.m(18 lb in).

  3. Connect the antenna cable to the rear window.
  4. Connect the antenna cable to the roof side rail using tape.
    Fig 1: Connect Antenna Cable & Antenna Cable Bracket Screw
    G01830765Courtesy of GENERAL MOTORS CORP.
  5. Connect the IP antenna extension cable to the antenna cable.
  6. Reposition the front carpet.
  7. Install the right front carpet retainer. Refer to CARPET RETAINER REPLACEMENT - FRONT
  8. Install the right instrument panel insulator. Refer to CLOSEOUT/INSULATOR PANEL REPLACEMENT - RIGHT
  9. Install the headliner. Refer to HEADLINER REPLACEMENT
    Fig 2: Connect IP Antenna Extension Cable To Antenna Cable
    G01830766Courtesy of GENERAL MOTORS CORP.
