Test E: Liftgate Window Release Is Inoperative With Transmitter

To perform test, see Fig 1 .

Fig 1: Test E: Liftgate Window Release Is Inoperative With Transmitter
G00125766Courtesy of GENERAL MOTORS CORP.
