Circuit Protection Devices
CIRCUIT PROTECTION DEVICES
| Component |
Component Location |
| Diode, A/C Compressor Clutch |
In underhood fuse center. |
| Diode, Daytime Running Lamps (DRL) |
On lower part of left "B" pillar. |
| Dash Fuse Block |
Behind left side of dash. See Figure. |
| Underhood Fuse/Relay Center |
On left side of firewall. See Figure. |
