Test A: Both Power Windows Do Not Operate

NOTE: For testing procedure, see Fig 1 .

Fig 1: Diagnostic Flow Chart: Both Power Windows Do Not Operate

G00116489

Courtesy of GENERAL MOTORS CORP.
