Tune-Up - V8: Engine: Notes
GENERAL SPECIFICATIONS
| Engine | Net HP At RPM | Torque (Ft.) | Compr. Ratio | Bore | Stroke | Displ. Cu. Ins. |
|---|---|---|---|---|---|---|
| 307" 2-Bbl. | 130 @ 4000 | 230 @ 2400 | 8.5-1 | 3.875" | 3.25" | 307" |
| 350" 2-Bbl. | 165 @ 4000 | 280 @ 2400 | 8.5-1 | 4.000" | 3.48" | 350" |
| 350" 4-Bbl. | 175 @ 4000 | 280 @ 2400 | 8.5-1 | 4.000" | 3.48" | 350" |
| 350" 4-Bbl. | 200 @ 4400 | 300 @ 2800 | 8.5-1 | 4.000" | 3.48" | 350" |
| 350" 4-Bbl. | 255 @ 5600 | 280 @ 4000 | 9.0-1 | 4.000" | 3.48" | 350" |
| 400" 2-Bbl. | 170 @ 3400 | 325 @ 2000 | 8.5-1 | 4.125" | 3.75" | 400" |
| 402" 4-Bbl. | 210 @ 4100 | 320 @ 2400 | 8.5-1 | 4.126" | 3.76" | 402" |
| 402" 4-Bbl. | 240 @ 4400 | 345 @ 3200 | 8.5-1 | 4.126" | 3.76" | 402" |
| 454" 4-Bbl. | 230 @ 4400 | 345 @ 3200 | 8.5-1 | 4.251" | 4.000" | 454" |
| 454" 4-Bbl. | 270 @ 4000 | 390 @ 3200 | 8.5-1 | 4.251" | 4.000" | 454" |
NOTE:
307", 402", & 454" Engines are not available for original Sale in California.
- NET HORSEPOWER & TORQUE NOTE: Horsepower and Torque figures given for 1972 are NET. NET Horsepower and Torque represent power at the flywheel when the engine is installed in vehicle, with wide open throttle and all systems operating such as, air cleaner, exhaust system, water pump, generator, oil pump and air conditioning.
