Air Cleaner Outlet Front Duct Replacement

Fig 1: Air Cleaner Outlet Front Duct

Courtesy of GENERAL MOTORS COMPANY

Callout	Component Name
Preliminary Procedure  Remove the aero shutter front bumper fascia air deflector. Refer to Aero Shutter Front Bumper Fascia Air Deflector Replacement (Sedan)Aero Shutter Front Bumper Fascia Air Deflector Replacement (Coupe) .
1	Air Cleaner Outlet Front Duct Procedure  Release the retaining tabs and rotate forward to remove.
