Installation Procedure

    Fig 1: Battery Negative Cable
    GM4246589Courtesy of GENERAL MOTORS COMPANY
  1. Install Battery Negative Cable (2)
    2. CAUTION:

    Refer to Fastener Caution

  2. Install Battery Post Negative Cable Clamp Nut (1) and tighten 4 N.m (35 lb in).
    3. Fig 2: Spare Tire
    GM4246588Courtesy of GENERAL MOTORS COMPANY
  3. Install Spare Tire (2)
  4. Spare Tire Stowage Retainer (1) Hand tighten
    5. Fig 3: Battery Cover
    GM4487810Courtesy of GENERAL MOTORS COMPANY
  5. Install Battery Cover (1)
  6. Install Battery Cover Bolt (2) and tighten 9 N.m (80 lb in)
    7. Fig 4: Rear Body Fuse Block Cover
    GM4487809Courtesy of GENERAL MOTORS COMPANY
  7. Install Rear Body Fuse Block Cover (1)
  8. Install Rear Compartment Floor Panel Trim Rear Compartment Floor Panel Trim Replacement
    9. NOTE:

    Start/Stop feature will not be available until the vehicle is allowed to sit for at least 3 hours undisturbed.

  9. If diagnosing a start/stop complaint, conduct the battery sensor module learn procedure to verify the repair. Refer to Battery Sensor Module Learn
