Air Cleaner Bracket Replacement
Air Cleaner Bracket Replacement
| Callout | Component Name |
|---|---|
| Preliminary Procedure Remove the air cleaner assembly. Refer to Air Cleaner Assembly Replacement . |
|
| 1 | Air Cleaner Bracket Fastener (Qty: 4)
CAUTION:
Refer to Fastener Caution Tighten 10 N.m(89 lb in) |
| 2 | Air Cleaner Bracket |
