Engine Components - Left Side (LSA)
Engine Components - Left Side (LSA)
| Component Name | Callout |
|---|---|
| Throttle Body | 1 |
| Evaporative Emissions (EVAP) Canister Purge Solenoid Valve | 2 |
| Supercharger Air Inlet Pressure Sensor | 3 |
| Manifold Absolute Pressure (MAP) Sensor | 4 |
| Intake Air Temperature (IAT) Sensor | 5 |
| Barometric Pressure (BARO) Sensor | 6 |
| Ignition Coil 7 | 7 |
| Ignition Coil 5 | 8 |
| Ignition Coil 3 | 9 |
| Ignition Coil 1 | 10 |
| Knock Sensor (KS) 1 | 11 |
| Engine Coolant Temperature (ECT) Sensor | 12 |
| Generator | 13 |
| Camshaft Position (CMP) Sensor | 14 |
