Exhaust Manifold Heat Shield Replacement - Right Side: Notes

    Fig 1: View Of Exhaust Manifold Heat Shield & Bolts
    GM1708619Courtesy of GENERAL MOTORS CORP.
  1. Remove the spark plug wires. Refer to Spark Plug Replacement .
  2. Remove the exhaust manifold heat shield bolts and heat shield from the exhaust manifold.
