Seat Belt Component Views

Fig 1: Driver Seat Area Components (Body Harness)

GM1657014

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	C315 Body Harness to Driver Seat Harness
2	G300
3	Inflatable Restraint Side Impact Module-Left Connector
4	G305
5	Yaw and Lateral Acceleration Sensor (JL4)
6	Inflatable Restraint Sensing and Diagnostic Module (SDM)
7	Inflatable Restraint Side Impact Sensor-Left
8	Seat Belt Pretensioner-LF
9	C Pillar

Fig 2: Passenger-RR Area

GM1657011

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	C Pillar
2	Seat Belt Pretensioner-RF
3	Inflatable Restraint Side Impact Sensor-Right
4	Inflatable Restraint Roof Rail Module-Right
5	Body Harness
