Installation Procedure

WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
  1. Connect the seat back heater harness.
  2. Install the seat back heater.
  3. Install the seat back trim cover. Refer to Seat Back Cover And Pad Replacement-Front   .
  4. Install the seat in the vehicle. Refer to Seat Replacement-Front Bucket   .
    Fig 1: Front Seat Back Heater Element
    G01579261Courtesy of GENERAL MOTORS CORP.
