Removal Procedure

WARNING: This page is about a different car, the 2004 Cadillac Seville. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Identifying Steering Wheel Control Switch & Electrical Connectors
    GM696506Courtesy of GENERAL MOTORS CORP.
  1. Using a flat bladed tool, carefully pry out on the top of the rear HVAC control.
  2. Remove the auxiliary HVAC control from the center console/seat.
  3. Disconnect the electrical connector.
  4. Remove the auxiliary HVAC control from the vehicle.
