Installation Procedure

WARNING: This page is about a different car, the 2003 Cadillac DeVille. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the hood (1) to the body with the aid of an assistant.
    NOTE: Refer to FASTENER NOTICE
  2. Install the bolts (2) that secure the upper hood hinge (3) to the lower hood hinge (5).

    Tighten

    Tighten the bolts to 9 N.m (80 lb in).

  3. Install the hood assist rods. Refer to ASSIST ROD REPLACEMENT - HOOD  .
  4. Connect the underhood electrical connector.
  5. Install the hood insulator. Refer to HOOD INSULATOR REPLACEMENT  .
  6. Adjust the hood if necessary. Refer to HOOD ADJUSTMENT  .
  7. Remove the tape from the hood and the fenders.
  8. Close the hood.
    Fig 1: Installing Hood And Hinge Pivot Bolts
    G02101556Courtesy of GENERAL MOTORS CORP.
