Installation Procedure

WARNING: This page is about a different car, the 2003 Cadillac CTS. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the rear compartment lamp (5) the rear carrier.
  2. Install the rear window shelf trim. Refer to INTERIOR TRIM .
    Fig 1: View Of Rear Compartment Lamp
    G02095144Courtesy of GENERAL MOTORS CORP.
