Removal Procedure

  1. Remove the overhead console. Refer to CONSOLE REPLACEMENT - OVERHEAD in Interior Trim.
  2. Disconnect the microphone (2) connector from the jumper harness.
    3. Fig 1: Removing OnStar Microphone
    G01457968Courtesy of GENERAL MOTORS CORP.
  3. Unclip the microphone bracket (1) from the overhead console.
  4. Disconnect the microphone 2-way connector (2) from the mating 2-way connector.
