Removal Procedure
CAUTION:
This vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions
- Air bag deployment
- Personal Injury
- Unnecessary SIR system repairs
In order to avoid the above conditions, observe the following guidelines:
- Refer to COMPONENT LOCATIONS in order to determine if you are performing service on or near the SIR components or the SIR wiring.
- If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to DISABLING & ACTIVATING AIR BAG SYSTEM .
CAUTION:
Before servicing any electrical component, the ignition key must be in the OFF or LOCK position and all electrical loads must be OFF, unless instructed otherwise in these procedures. If a tool or equipment could easily come in contact with a live exposed electrical terminal, also disconnect the negative battery cable. Failure to follow these precautions may cause personal injury and/or damage to the vehicle or its components
- Turn OFF all the lamps and accessories.
- Make sure the ignition switch is OFF.
- Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR .
- Remove the negative battery cable from the battery.
