Removal Procedure

  1. Raise the drivers seat to the full forward and upward position.
  2. Position outward the seat spring wires (2) retaining the memory seat module to the seat bottom cushion frame.
  3. Disconnect the electrical connectors.
  4. Remove the memory seat module (1).
    Fig 1: Identifying Seat Spring Wires & Memory Seat Module
    G01665996Courtesy of GENERAL MOTORS CORP.
