Actuator Drive Cables
Remove rear seat cushion and seat back. Disconnect drive cable at top actuator assembly. Disconnect cable, right or left, at motor reduction gear unit.
NOTE:
For removal or left cable, first remove motor from support bracket.
To install, reverse removal procedure. To aid cable engagement, push and rotate cable opening on actuator by finger or with suitable tool.
