Removal Procedure

Courtesy of GENERAL MOTORS COMPANY

Front Floor Console Assembly (1) - Remove - Front Floor Console Replacement
Courtesy of GENERAL MOTORS COMPANY

Front Floor Console Storage Tray (2) - Remove - Front Floor Console Stowage Tray Replacement
Courtesy of GENERAL MOTORS COMPANY

Floor Rear Air Outlet Duct Adapter- Left Side (1) - Remove - Floor Rear Air Outlet Duct Adapter Replacement - Left Side
Courtesy of GENERAL MOTORS COMPANY

Floor Rear Air Outlet Duct Adapter- Right Side (1) - Remove - Floor Rear Air Outlet Duct Adapter Replacement - Right Side
Courtesy of GENERAL MOTORS COMPANY

Automatic Transmission Range Selector Lever Cable Bolt (1) - Remove
Reposition the automatic transmission range selector lever cable (2) to remove the body control module.
Courtesy of GENERAL MOTORS COMPANY

Disconnect the body control module electrical connectors (1).
Courtesy of GENERAL MOTORS COMPANY

Body Control Module (1) @ Body Control Module Bracket - Remove
