Removal Procedure

  1. GM4626799Courtesy of GENERAL MOTORS COMPANY

    Upper Intermediate Steering Shaft (3) @ Intermediate Steering Shaft - Disconnect - Upper Intermediate Steering Shaft Replacement

  2. Upper Intermediate Steering Shaft (3) & Intermediate Steering Shaft Boot- Upper (1) - Position aside
  3. GM4876351Courtesy of GENERAL MOTORS COMPANY

    Intermediate Steering Shaft Boot Bolt- Inner (1) - Remove [3x]

  4. Lift the lip of the intermediate steering shaft inner boot and release the boot from the intermediate steering shaft pass through.
  5. GM4876352Courtesy of GENERAL MOTORS COMPANY

    Intermediate Steering Shaft Boot- Inner (1) - Remove
