Head-Up Display Bracket Replacement

Fig 1: Head-Up Display Bracket
GM3976661Courtesy of GENERAL MOTORS COMPANY
Callout Component Name
Preliminary Procedure
Head-Up Display Replacement
1 Instrument Panel Accessory Bracket Bolt (Qty: 4)
CAUTION:

Refer to Fastener Caution .


Tighten
9 N.m (80 lb in)
2 Head-Up Display Bracket
