Roof Console Replacement

WARNING: This page is about a different car, the 2011 Buick Regal. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Roof Console And Fasteners

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
Preliminary Procedure: Remove the roof console reading lamp bezel. Refer to Roof Console Reading Lamp Bezel Replacement .
1	Roof Console Fastener (Qty: 2) CAUTION: Refer to Fastener Caution .
3	Roof Console Assembly Procedures Use a flat-bladed plastic trim tool to release the retainers along the forward edge of the console assembly releasing the roof console from the headliner. Pull the roof console assembly forward releasing the alignment tabs along the rear edge of the console assembly. Disconnect the electrical connections. When replacing the roof console assembly, transfer all necessary components.

Callout

Component Name

Preliminary Procedure:
Remove the roof console reading lamp bezel. Refer to Roof Console Reading Lamp Bezel Replacement .

Roof Console Fastener (Qty: 2)

CAUTION: Refer to Fastener Caution .

Roof Console Assembly

Procedures

Use a flat-bladed plastic trim tool to release the retainers along the forward edge of the console assembly releasing the roof console from the headliner.
Pull the roof console assembly forward releasing the alignment tabs along the rear edge of the console assembly.
Disconnect the electrical connections.
When replacing the roof console assembly, transfer all necessary components.
