Sunroof Window Motor Replacement

WARNING: This page is about a different car, the 2011 Buick Regal. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Sunroof Window Motor

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
1	Sunroof Window Motor Fastener (Qty: 3) WARNING: Disconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury. CAUTION: Refer to Fastener Caution Procedure Disconnect the electrical wiring harness connector. Remove the roof console to access the sunroof window motor. Refer to Roof Console Replacement . Tighten: 4 N.m (35 lb in)
2	Sunroof Window Motor Procedure When replacing the sunroof motor, refer to Sunroof Motor/Actuator Initialization/Teach Process (New Motor) or Sunroof Motor/Actuator Initialization/Teach Process (Existing Motor) . Verify the operation of the sunroof before installing the headliner.

Callout

Component Name

Sunroof Window Motor Fastener (Qty: 3)

WARNING: Disconnect the power window switch when working inside the driver door. When operated, the Express Up/Down Feature allows the door window to move very quickly, without stopping, which could cause personal injury.

CAUTION: Refer to Fastener Caution

Procedure

Disconnect the electrical wiring harness connector.
Remove the roof console to access the sunroof window motor. Refer to Roof Console Replacement .

Tighten: 4 N.m (35 lb in)

Sunroof Window Motor

Procedure

When replacing the sunroof motor, refer to Sunroof Motor/Actuator Initialization/Teach Process (New Motor) or Sunroof Motor/Actuator Initialization/Teach Process (Existing Motor) .
Verify the operation of the sunroof before installing the headliner.
