Installation Procedure

WARNING: This page is about a different car, the 2004 Buick Regal and 2004 Buick Century. However, it is still accessible from the selected car via links, so may be relevant.
    Fig 1: Rear Compartment Lid Switch & Electrical Connector
    GM1245887Courtesy of GENERAL MOTORS CORP.
  1. Connect the electrical connector to the lid release switch.
  2. Press the lid release switch into the I/P opening.
  3. Close the I/P compartment door.
