Engine Control System Self-Diagnostics - 3.8L
>>
Diagnostic Tests
>>
DTC P1640: Output Driver Module Circuit No. 1
>>
Diagnostic Procedures
Diagnostic Procedures
Fig 1: DTC P1640: Output Driver Module Circuit No. 1
Courtesy of GENERAL MOTORS CORP.
