Installation Procedure

  1. Clean the surface of the rear shelf in the GPS antenna mounting location, using an isopropyl alcohol pad and a clean lint-free cloth.
    IMPORTANT: Do not touch the adhesive backing.
  2. Remove the protective backing from the adhesive of the GPS antenna.
  3. Install the GPS antenna to the rear shelf surface.

    Press the GPS antenna into place for approximately 30 seconds until fully seated.

  4. Connect the GPS antenna cable connector.
    Fig 1: Connecting GPS Antenna Cable Connector
    G01587345Courtesy of GENERAL MOTORS CORP.
  5. Install the rear shelf trim panel. Refer to TRIM PANEL REPLACEMENT - REAR WINDOW SHELF in Interior Trim.
