Removal Procedure

WARNING: This page is about a different car, the 2005 Buick LeSabre. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the right instrument panel accessory trim plate. Refer to Trim Plate Replacement - Instrument Panel (I/P) Accessory Right in Instrument Panel, Gages and Console.
    2. Fig 1: View of HVAC Control Module and Right I/P Accessory Trim Plate
    GM443866Courtesy of GENERAL MOTORS CORP.
  2. Pinch the tabs on the A/C control module and pull rearward on the HVAC control module to remove from the instrument panel.
