Test Description

  1. Determine a keyless entry system fault or trunk lid release system fault.
  2. Tests transmission position switch. With transmission in Park, transmission position switch should be closed, applying voltage to circuit No. 275.
Fig 1: Trunk Lid Release Inoperative; Schematic
G93I40897Courtesy of GENERAL MOTORS CORP.
Fig 2: Trunk Lid Release Inoperative; Flow Chart
G93J40898Courtesy of GENERAL MOTORS CORP.
