Install the upper slide rail
NOTE:
The figure shows cylinders 1 to 6.
- Install the slide rail (3)
.
- Tighten down screws (1)
and (2)
.
TIGHTENING TORQUE SPECIFICATIONS
| Sliding rail to cylinder head |
| M7X45 |
Tightening torque |
15 Nm |
 Courtesy of BMW OF NORTH AMERICA, INC.
|
