33 32... Overview of steering links

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2013 BMW 335is, 2013 BMW 335i, 2012 BMW 335is, 2012 BMW 335i, and 2011 BMW 335is. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Overview Of Steering Links
G09860521Courtesy of BMW OF NORTH AMERICA, INC.
