Removal & Installation

Take off cap. Unscrew screw. Pull accelerator pedal module upwards out of fixture.

Fig 1: Removing Cap

Courtesy of BMW OF NORTH AMERICA, INC.

Pull off plug (1). Remove accelerator pedal module. See Fig 2 . Accelerator pedal module can only be replaced completely with adapter plate. See TORQUE SPECIFICATIONS  .

Fig 2: Removing Accelerator Pedal Module

Courtesy of BMW OF NORTH AMERICA, INC.
