General Electrical New Features: CAS

The Car Access System control unit functions as the master for power window functions:

• Operation by radio remote control key
• Central-locking interface
• Country-specific programming
• Child lock
• Comfort functions (One-Touch)
  Fig 1: Car Access System

  Courtesy of BMW OF NORTH AMERICA, INC.
