Special tools and workshop equipment required

• Pry Lever:80-200
• Transmission Support:3282
• Transmission Support - Pins 29:3282/29
• Transmission Support - Mounting Plate 42A:3282/42A
• Engine Bung Set:VAS6122
• Engine and Gearbox Jack:VAS6931

Fig 1: Identifying Special Tools -- Securing Transmission To Assembly Stand

Courtesy of AUDI OF AMERICA, LLC

Special tools and workshop equipment required

• Holding Plate:VW309A
• Holding Fixture:VW313  or
• Engine and Gearbox Bracket:VAS6095A
• Transmission Support:VW353
• Holding Fixture:VW540

Special tools and workshop equipment required

• Used Oil Collection and Extraction Unit:SMN372500
  Fig 2: Identifying Used Oil Collection And Extraction Unit

  Courtesy of AUDI OF AMERICA, LLC
• Wrench - Pump/Injector Long Reach:T10054

  Courtesy of AUDI OF AMERICA, LLC

• Socket And Extended Bit:T10107A
  Fig 3: Identifying Socket And Extended Bit

  Courtesy of AUDI OF AMERICA, LLC
• Wedge Set:T10383
  Fig 4: Identifying Wedge Set

  Courtesy of AUDI OF AMERICA, LLC
• Locking Button Removal Tool:T40203
  Fig 5: Identifying Release Tool T140203

  Courtesy of AUDI OF AMERICA, LLC
• Shop Crane:VAS6100
  Fig 6: Identifying Shop Crane

  Courtesy of AUDI OF AMERICA, LLC
• Oil Filler:VAS6262A
  Fig 7: Identifying Oil Filler Adapter

  Courtesy of AUDI OF AMERICA, LLC
• If necessary: Oil Filler - Adapter 6:VAS6262/6  or Oil Filler - Adapter:VAS6262/7
  Fig 8: Identifying Adapter

  Courtesy of AUDI OF AMERICA, LLC
• Engine Support Bridge - Additional Hooks (2 pc.):10-222A/2
  Fig 9: Engine Support Bridge Hooks 10-222 A /2

  Courtesy of AUDI OF AMERICA, LLC
• Engine/Gearbox Support Shackle (2 pc.):10-222A/12
  Fig 10: Engine/Gearbox Support Shackle (10-222A/12)

  Courtesy of AUDI OF AMERICA, LLC
• Engine Support Bridge - Special Hook (2 pc.):10-222A/20
  Fig 11: Identifying Special Hook (2 pc.)

  Courtesy of AUDI OF AMERICA, LLC
• Engine Sling - Engine Bracket:2024A/1
  Fig 12: Engine Sling - Engine Bracket

  Courtesy of AUDI OF AMERICA, LLC
• Hose Clamps - Up To 25mm:3094
  Fig 13: Hose Clamps

  Courtesy of AUDI OF AMERICA, LLC
• Engine Support Device:3300A

  Courtesy of AUDI OF AMERICA, LLC

• Trim Removal Wedge:3409
  Fig 14: Identifying Trim Removal Wedge

  Courtesy of AUDI OF AMERICA, LLC
• Vehicle Diagnostic Tester
