Overview - Peripheral Camera
- Right Peripheral Camera -R245-/Left Peripheral Camera - R244-
- Removing and installing. Refer to Right/Left Peripheral Cameras -R244- /-R245-, Removing and Installing
- Calibrating. Refer to Peripheral Camera, Calibrating
- Bracket
- Bolt
- 2 Nm
- Quantity: 2
- Peripheral Camera Control Module - J928-
- Behind the left luggage compartment side trim panel
- Refer to Wiring diagrams, Troubleshooting & Component locations
- Removing and Installing. Refer to Peripheral Camera Control Module - J928-, Removing and Installing
- Calibrating. Refer to Peripheral Camera, Calibrating
- Bracket
- Rear Peripheral Camera - R246-
- Removing and installing. Refer to Rear Peripheral Camera - R246-, Removing and Installing
- Calibrating. Refer to Peripheral Camera, Calibrating
- Nut
- 3 Nm
- Quantity: 2
- Bolt
- 3 Nm
- Quantity: 2
- Front Peripheral Camera - R243-
- Removing and installing. Refer to Front Peripheral Camera - R243-, Removing and Installing
- Calibrating. Refer to Peripheral Camera, Calibrating
