Special Tools

Special tools and workshop equipment required

• Front Door Template:T40038/10  for the front door.
• Rear Door Template:T40038/11  for the rear door.
• Use the Door Adjustment Template:T40038/10  on the front door with the side -A- for the front measuring point on the B-pillar or -B- for the rear measuring point on the B-pillar.
  Fig 1: Identifying Door Adjustment Template T40038 /10

  Courtesy of AUDI OF AMERICA, LLC
• Window Slot Seal Tool:T40219
  Fig 2: Identifying Window Slot Seal Tool T40219

  Courtesy of AUDI OF AMERICA, LLC
• Adhesive Strip Remover:VAS6349
  Fig 3: Adhesive Remover VAS 6349

  Courtesy of AUDI OF AMERICA, LLC
• Roller:3356
  Fig 4: Application Roller 3356

  Courtesy of AUDI OF AMERICA, LLC
• Gauge - Gap Adjustment:3371
  Fig 5: 3371 Special Tool

  Courtesy of AUDI OF AMERICA, LLC
• Pry Lever:80-200
  Fig 6: 80-200 Pry Lever

  Courtesy of AUDI OF AMERICA, LLC
• The front door and the rear door have different templates.
• The min and max markings are used to check the lateral adjustment.
• The groove in the center of the template is used for checking the height.
• The 0.6 mm graduation on the ends of the template is used for checking the recess of the front door to the fender, or of the rear door to the front door.
