General Description For Start/Stop System

Fig 1: Identifying Battery Overview

Courtesy of AUDI OF AMERICA, LLC

1. Voltage Stabilizer -J532-
   • Removing and installing. Refer to VOLTAGE STABILIZER, REMOVING AND INSTALLING .
2. Nut
   • 3 Nm
3. Nut
   • 3 Nm
4. Cover/Multimedia System Control Head -E380-
5. Start/Stop Mode Button -E693-
   • Various installed locations
   • Removing and installing. Refer to Start/Stop Mode Button -E693-, REMOVING AND INSTALLING .
6. Nut
   • 3 Nm
7. Bracket
   • For the Voltage Stabilizer -J532-
8. Connector
