Fastener Tightening Specifications
WARNING: This page is about a different variant/trim than selected.
| Component | Bolt Size | Nm |
|---|---|---|
| Engine mount tightening specification | - | Figure |
| Engine support | - | 40 |
| Right transmission mount brace | - | 20 |
| Subframe, nut | - | 20 |
| Bolts and nuts | ||
| M6 | 9 | |
| M7 | 15 | |
| M8 | 20 | |
| M10 | 40 | |
| M12 | 65 | |
