| 1 |
Terminal 15, from Fuse Panel F -SF- |
1 |
Power Supply front sensor |
1 |
|
| 2 |
Rear Parking Aid Warning Buzzer -H15- |
2 |
Ground front sensor |
2 |
Right Rear Center Parking Aid Sensor -G205- |
| 3 |
|
3 |
Front Parking Aid Warning Buzzer -H22- |
3 |
Left Rear Center Parking Aid Sensor -G204- |
| 4 |
Parking Aid Button -E266- |
4 |
Front Parking Aid Warning Buzzer -H22- |
4 |
Right Rear Parking Aid Sensor -G206- |
| 5 |
|
5 |
Left Front Parking Aid Sensor -G255- |
5 |
Left Rear Parking Aid Sensor -G203- |
| 6 |
CAN-Bus, High |
6 |
Left Front Center Parking Aid Sensor -G254- |
6 |
Right rear parallel parking assistance sensor -G717- |
| 7 |
|
7 |
Right Front Center Parking Aid Sensor -G253- |
7 |
|
| 8 |
Terminal 31, to 51 Ground connection in luggage compartment, right |
8 |
Right Front Parking Aid Sensor -G252- |
8 |
Ground rear sensor |
| 9 |
Parallel Parking Assistance Indicator Lamp -K241- |
9 |
Left Front Parallel Parking Assistance Sensor, left model side -G568- |
9 |
|
| 10 |
Rear Parking Aid Warning Buzzer -H15- |
10 |
Right Front Parallel Parking Assistance Sensor, right model side -G569- |
10 |
Left rear parallel parking assistance sensor -G716- |
| 11 |
|
11 |
|
11 |
Power supply rear sensor |
| 12 |
|
12 |
|
12 |
|
| 13 |
Parking Aid Indicator Lamp -K136- |
|
|
|
|
| 14 |
|
|
|
|
|
| 15 |
CAN-Bus, Low |
|
|
|
|
| 16 |
Parallel Parking Assistance Button -E581- |
|
|
|
|
