Garage Door Opener Control Module Connector End View (J530, T4ak)
Garage Door Opener Control Module Connector End View (J530, T4ak)
Fig 1: Garage Door Opener Control Module Connector End View (J530, T4ak)
Courtesy of AUDI OF AMERICA, LLC
A
5-Pin Connector -T4ak-
Courtesy of AUDI OF AMERICA, LLC
