Component overview: Notes
1 - Front Passengers Door Control Module -J387-
- Integrated in window regulator.
2 - Door control module, rear, right -J389-
- Integrated in window regulator.
3 - Fuel Tank Lid Unlock Motor -V155-
4 - Rear Lid Control Module -J605-
5 - Comfort System Central Control Module -J393-
- Component location, in right rear side panel → Central control module for comfort system .
6 - Rear Lid Unlock Motor -V155-
7 - Door control module, rear, left -J388-
- Integrated in window regulator.
8 - Drivers Door Control Module -J386-
- Integrated in window regulator.
9 - Front Hood Switch -F266-
- Component location in lock carrier
