Engine Speed Sensor -G28-, REMOVING AND INSTALLING: Removing

-- Remove the noise insulation by loosening the fastening elements -1, 2 and 3-.

Fig 1: Noise Insulation Components

Courtesy of AUDI OF AMERICA, LLC

-- Disconnect the connector -2-.

Fig 2: Locating Engine Speed (RPM) Sensor -G28-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolt -1- and the Engine Speed Sensor -G300-.
