Special Tools

WARNING: This page is about a different car, the 2012 Audi Q5, 2011 Audi Q5, 2010 Audi Q5, and 2009 Audi Q5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Special Tools -- Engine, Removing

Courtesy of AUDI OF AMERICA, LLC

Special tools and workshop equipment required

Used Oil Collection and Extraction Unit SMN372500
Hose Clip Pliers VAG1921
Step Ladder VAS5085
Scissor Lift Table VAS6131B with Scissor Lift Table - Audi Set VAS6131/10, Scissor Lift Table - A8 Set VAS6131/11 and Scissor Lift Table - Q7 Set VAS6131/13
Shop Crane - Drip Tray VAS6208

Fig 2: Identifying Special Tools - Engine, Securing To Engine And Transmission Holder

Courtesy of AUDI OF AMERICA, LLC

Special tools and workshop equipment required

Engine Sling 2024A
Engine And Transmission Holder VAS6095 with Engine/Transmission Holder - V6 FSI Bracket VAS6095/1-5
Shop Crane VAS6100
Lift Arm Extension VAS6101

Special tools and workshop equipment required

Used Oil Collection and Extraction Unit SMN372500

Fig 3: Used Oil Collection and Extraction Unit SMN372500
Courtesy of AUDI OF AMERICA, LLC
Engine Bung Set VAS6122

Fig 4: Engine Bung Set VAS6122
Courtesy of AUDI OF AMERICA, LLC
Counterhold - Kit T10172/2-9 with Counterhold - Kit - Adapter 5 T10172/5

Fig 5: Counterhold - Kit T10172/2-9
Courtesy of AUDI OF AMERICA, LLC
Crankshaft Socket T40058

Fig 6: Crankshaft Socket T40058
Courtesy of AUDI OF AMERICA, LLC
Engine Support - Supplement Kit T40093A

Fig 7: Engine Support - Supplement Kit T40093A
Courtesy of AUDI OF AMERICA, LLC
Clutch Module Transportation Lock T40170

Fig 8: Clutch Module Transportation Lock T40170
Courtesy of AUDI OF AMERICA, LLC
Torque Wrench 1332 Insert - Ring Wrench - 16mm VAG1332/14

Fig 9: Insert Ring Wrench - 16mm VAG 1332/14
Courtesy of AUDI OF AMERICA, LLC
Engine Support Bridge 10-222A

Fig 10: Engine Support Bridge 10-222A
Courtesy of AUDI OF AMERICA, LLC
Pry Lever 80-200
Scissor Lift Table - Gearbox Support VAS6131/14
