Wheel Change Initialization

NOTE: If tire or tire pressure sensor was changed, the TPMS must be initialized.
NOTE: Initialization process can take up to 20 minutes. During this time, the sensors are readjusting to the new wheel/tire combination and the monitoring system is operating at reduced sensitivity. The system will only warn when tire pressure drops below the minimum permissible specified pressure (warning symbol and message will appear).
  1. Ensure air pressure in all tires (including spare tire) is properly adjusted to specification.
  2. On the center instrument cluster display, press the MENU button. See Figure.
  3. Push the turn-switch to select "SET" option. See Figure.
  4. Turn the switch to scroll to "TYRE PRESSURE", then push switch. See Figure.
  5. Push the switch again to select "WHEEL CHANGE". See Fig 1.
Fig 1: Initializing New Wheels
G00225465Courtesy of AUDI OF AMERICA, INC.
