Application of PR Nos./brakes
The PR No. on the vehicle data sticker indicates the type of brakes installed in the vehicle.
- Arrow 1 - Rear brake
- Arrow 2 - Front brake
The vehicle data sticker is located in the spare wheel recess and in service booklet.
The PR No. can be used to identify the proper brake caliper/brake disc/brake pad combination.
| Engine | PR No. | Front brake |
| 1.8 ltr. - 110 kW 1.8 ltr. - 132 kW 1.8 ltr. - 165 kW |
1LT | FN 3 (16") |
| 1.8 ltr. - 132 kW | G1A, 1LV | FN 3 (16") |
| 3.2 l - 184 kW | 1ZT | 2 FN 42 (17") |
| Engine | PR No. | Rear brake |
| Front-wheel drive | ||
| 1.8 ltr. - 110 kW 1.8 ltr. - 132 kW |
1KK | C 38 |
| 1.8 ltr. - 132 kW | 2EK | C 38 |
| All wheel drive | ||
| 1.8 ltr. - 132 kW | 1KE | C 41 |
| 1.8 ltr. - 165 kW | 1KF | C 38 |
| 3.2 ltr. - 184 kW | 1KF | C 38 |
