Test procedure

• Connect VAS 5051 Vehicle Diagnosis, Measurement and Information System. See VAS 5051 VEHICLE DIAGNOSIS, MEASUREMENT AND INFORMATION SYSTEM, CONNECTING AND SELECTING FUNCTIONS  and select vehicle system "02 Transmission Electronics". Ignition must be switched on.

Display on VAS 5051

Fig 1: Display on VAS 5051 - Transmission Control Module Coding (1 Of 4)

Courtesy of AUDI OF AMERICA, INC.

• Touch -1- diagnostic function "07 Coding control module".

Display on VAS 5051:

Fig 2: Display on VAS 5051 - Transmission Control Module Coding (2 Of 4)

Courtesy of AUDI OF AMERICA, INC.

1. Enter code word

• On keypad -2- enter control module code as given in code chart.
• Confirm entry by pressing Q button.
